Analog polysynth (1983)
Company: Siel
Model: kiwi
Class: synthesizer
Keyboard: 61 keys with velocity
Dates: 1983
Country: italy
Weight: 15 Kg
Dimensions: 90 mm x 39 mm x 18 cm
Price: 400€
Display: none
Technology: analog
Polyphony: 6 voices
Multitimbric: 1 part
Oscillator: 2 DCO saw + pulse
Filter: 1 VCF LP 24dB/oct
Envelope: 1 EGS ADSR type
Effect: none
MODULATION: 3 LFOs
Memory: 95 slots
Midi: in / out
PSU: internal
IC: 6X SSM2024 VCA (Quad Current Controlled Amplifier)
6X SSM2056 EG (Voltage Controlled Transient Generator)
6X SSM 2044 VCF (4-Pole Voltage Controlled Filter)
2X SSM2031 (High Frequency Oscillator) + TMS3631AN
61 keys keyboard with 2 wheels:
- pitch (to DCO1 and or DCO2)
- modulation (depth to LFO1 and or LFO2/3)
Rear panel connectors:
-Midi IN / OUT / THRU
- mono output
- I/O for tape (with switch tab mode)
- 5 din connector for VCA CV control
-5 din connector for VCF CV control
none yet
- No official VST plugin
- No user manual yet
- No service manual yet
Scegli tra la vasta selezione di blocchi già pronti più recenti: intro a tutto schermo, caroselli immagini di bootstrap, Slider dei contenuti, galleria di immagini responsive con lightbox, parallax-scrolling, sfondi video, menu hamburger, intestazioni fisse e altro ancora.
VOICE main system CPU is based around Texas Instruments TMS7000. Custom IC TMS3631AN generates 6 voices polyphony with 2 detunable oscillators DCO1 / DCO2 with 3 footages at 4' 8' 16'.
Each oscillator features 2 mixables (only 50% volume) shapes and a noise generator with no control (but volume) can be mixed to DCO.
-2 oscillator per voice at 4' 8' 16'
- sawtooth / pulse shape
- DCO2 detune coarse+ fine
up to 6 voices, no split, no stack
Pink noise generator with volume control
4 different keyboard curves sensivity: high/medium1/medium2/low
the VCF is a low pass type 24dB/oct resonant
- keytracking mode
- 2 separate modulators for DCO pitch
- extra dedicated LFO for pulse width and filter cutoff
-1 EG generator assignable to:
VCA / VCF
The dynamics destination (velocity) can be assigned to either ADSR level or Attack time.
The Kiwi is sysex compatible, some old editors maybe for commodore64. No info about this for now.
The kiwi holds up to 95 patches. Memory system works with a battery with frequent leakage issues.
- unreliable
- 1 EG
- very basic
-vintage
- lot of good IC
- sounds nice
