GEM Wizard 315

Organ (1980?)

Gem wizard organ 315

"Pretty old organ with drum rhytm machine and auto-accompaniment. Should be a bigger version of GEM Sprinter 61 organ with same specs but no speakers. "

 Overview

VOICE Main voice circuit is based on   DIP40 M108 B1 (SGS / ST Integrated Circuit M108B1 Electronic Organ + Accompaniment).
The Gem Wizard 315 is organized in 4 main sections:
- organ with register: with percussion and 3 register flute 16' 8' 4'
- synthesizer with preset : 7 preset with SOFT / LOUD option piano, harpsichord, accordion, synth, brass, vibrafone and pan flute
- drum machine preset: 8 presets: latin, rock, disco, swing, blues, walts, tango and march.
- auto-accompaniment: It's the magic chords system, not sure how this works!

315 main board

Connections

TERMINAL CONNECTORS:
-Main out
-Volume pedal Input
-Headphones (front)

gem wizard 315

GEM 315 wizard technical specifications

Company: GEM
Model: 315 wizard
Class: organ with internal speakers
Keyboard: 61 non dynamics
Dates: 1980?
Country: Italy
Weight: / Kg
Dimensions: / mm
Actual price: 100+€
Display: none
Technology: analog
Oscillator: none
Filter: none
Envelope: Sustain
Effect: vibrato
Memory: 7 presets + organ section + 8 drum patterns
Tempo: only internal. no external sync
Midi: none
PSU: internal
Sync: none
OS: must be kiddin'!
IC: TDA2030 / M108 B1

gem Wizard 315

Are you a WIZARD 315 user? do you like it? You do not agree with our review?  Let us know in the comment field just below
