Ensoniq KT-88
64 Voice Weighted Action Workstation (1994)
64 Voice Weighted Action Workstation (1994)
Company: Ensoniq
Model: KT-88
Class: Workstation
technology: rompler
Wavetable: 211 PCM (3x2 MB ROM)
Keyboard: 88 dynamic keys
Velocity curves: 14 models
Dates: 1994
Country: United States
Weight: / Kg
Dimensions: / mm
Price: 300€
Display: LCD 32 chars
Tuning table: 30 presets
Multitimbric: 16 parts
Oscillator: 3 PCM per voice max
Filter: 2 x 2 poles digital resonante filter (Low pass or High pass)
Envelope: 3 digital envelope
Effect: 13 algorithm models
Midi: IN / OUT / THRU
Sequencer: onboard 16 tracks
Sequencer Memory: 6500 notes expandable to 100,000 with a PCMCIA card
Sound Memory: 100 RAM + 80 ROM
Storage: MC-512 PCMCIA RAM
CPU: MC68EC020FG 25 MHz
OS: on two EPROMS LO + HI
PSU: internal
IC: OTTOR2C (2x same found on some earlier pc soundcard) / ESPR6 609-0390750 Custom Programmable DSP
88 keys with pressure, transpose function, 2 wheel for modulation and pitch bender.
All data are edited with single Data slider.
Rear panel connectors:
-Midi I/O
-single (mono) or a dual (stereo) foot switch input
-Cv pedal input
-Stereo out
Front:
-headphones
-PCMCIA slot card
- FACTORY SYSEX DOWNLOAD
- No official VST plugin
- owner's manual download
- Service manual and schematics (contact us if you have it)
How to Reinitialize the KT
1.Press the {EDIT_SEQ/PRESET}button.
2.While holding down the upper {9}bbutton, press the lower {9} button.
3.press yes ! DONE!
Scegli tra la vasta selezione di blocchi già pronti più recenti: intro a tutto schermo, caroselli immagini di bootstrap, Slider dei contenuti, galleria di immagini responsive con lightbox, parallax-scrolling, sfondi video, menu hamburger, intestazioni fisse e altro ancora.
VOICE main CPU MC68EC020FG handles 64 voices polyphony.
Each voice is composed by a maxium of 3 PCM samples (1 voice per sample) out of a 211 wavetable which is organized into 14 categories, including famous "transwave" synthesizer sounds.
Sample can be played with delay, backward, with start point.
Motorola MC68EC020FG
64 voices polyphony, up to 3 PCM per voice.
Special Drum mode.
211 PCM multisampled at 16 bits
-30 tuning scales
- 2 mono modes with glide / legato
-13 algorithm effects (revern, delay, chorus, phaser, leslie)
- 4 velocity curves (linear, convex, concave, quickrise)
-Special General Midi mode
- 16 tracks internal sequencer
digital resonant filter stage comprised of two multi-mode digital filter that can be set in 4 modes between LP (low pass) and HP (high pass):
- 3LP / 1LP
- 2LP / 2LP
- 3LP / 1HP
- 2LP / 2HP
1 single delayed modulator (7 shapes: triangle, sinewave, square,mix of a sine and triangle wave, positive sinewave, a positive-only triangle and sawtooth) ) can be Midi clock Sync or freerun mode (no retrig).
Modulation Matrix 15 routable modulation sources: noise (x2) LFO, EG (x3), wheel, wheel +pressure, pitch bender, CV pedal, Midi CC, Aftertouch, Keyb tracking, velocity)
3 digital EG each with following data:
-Times: Attack, Decay1, 2, Release
-Levels: Peak, Break, Sustain
-39 preset envelope shapes
Sequencer Memory: 6500 notes expandable to 100,000 with a PCMCIA card
Sound Memory: 100 RAM + 80 ROM with "soundfinder" tool
Internal Lithium CR2032 soldered to the mainboard
- old wavetable
- bulky
- may need maintenance
-now cheap
- transwave technology
