Casio GZ-50M

GM sound module (1995)

casio gz50M

"Affordable Midi Gm module player with no control"

Overview

KEYBOARD very simple half rack module, white metal case wit minimal control but power switch (with led), Midi activity led, a demo button, main volume control and headphones output.

TERMINAL CONNECTORS
- Midi INPUT
- LEFT and RIGHT audio out
- PSU input 9VDC with negative center


casio gz50m

Sound and effects

SOUND Main 16 bits CPU is a HD6433298A42F, DAC UPD6376GS.
The unit mainly play Midi files using a  2MB wavetable samples with 32 notes polyphony, up to 16 standard parts with 128 GM sounds (piano, organ, strings, trumpet...) and 8 drum sets. It is not possible to edit sound, maybe using midi exclusives.

EFFECTS based on DSP HG51B115FD :offers Reverb ,Chorus, Tremolo, Phaser, Shifter Organ, SP Enhancer, Flanger, EQ and Loudness

casio gz50m

Casio GZ-50M Specifications

Manufacturer CASIO (Japan)
Release date  1995
Country: Japan
Price: 50€
Synthesis: PCM rompler
Class: desktop module
Supported sound source formats GM
Sound source method WAVE TABLE sound source
Waveform memory 2MB
Maximum polyphony 32 sounds
Number of parts 16 parts
Number of timbres 128 tones
drum set 8 drum set
Effect:  Reverb Type 3 Chorus Tremolo Phaser Shifter Organ SP  Enhancer Flanger EQ Loudness

Power source:AC source only: AC adapterPower consumption:2.8 W
Dimensions (HWD):35 x 113 x 169 mm (1-3/8 x 4-7/16 x 6-5/8 inches)
Weight:450 g (1 lbs)

GZ50m

video demo
