Roland M-OC1





roland m-oc1

info Country: Japan
Weight: 2,6 Kg
Dimensions: n/a
audio demo trend price : 100€
manual demo comments

Roland M-OC1
Orchestra module (1995)



The sound expansion series were standalone version of SR-JV expansion cards for modules like JV-1080 or 2080 and workstations like Xp-50.

The MOC1 is the equivalent of the SRJV-02 orchestral expansion.

roland moc1 title
roland moc1

info RACKMOUNT 1 unit module with 11 buttons and a 7-segments display.

Rear panel terminal connectors:
- Midi interface
- main output
- signal line input (signal not processed)


Front panel terminal connectors:
- headphones.




edit VOICE core 16 bits microcontroller HF6415108F (part of HD6415 / h8 family) manages 28 voices polyphony.
Synthesis based on subtractive synthesis: each patch is composed by 1, 2, 3 or 4 PCM samples layers. The module is more like a preset machine since all sounds are ready to go and it not possible to edit from direct panel - most parameters can be changes only using an external Midi SYSEX strings generator.



architecture



roland moc1



edit WAVETABLE 188 samples mainly focused on orchestral instruments including strings, harps, oboes, horns, trumpets, violas, cellos, trombones and more.
Also many instruments like violins have been recorded in various modes including:
- spiccato
- fast
- legato
- ensemble.

samples



editPERFORMANCE MOC1 handles up to 7 parts + 1 drum.
Each part can be set with a single patch with variable multitimbral parameters:
- reverb and chorus level
- volume / panning
- pitch detune
- Midi channel.


parts


edit FILTER section is based on digital TVF Time-Variant-Filter and 3 modes:
- lowpass
- bandpass
- highpass.


filter




edit
LFO 2 modulators features 7 shapes: triangle, sinewave, sawtooth, trapezoidal, random, sample & hold and a variation called chaos random.
Destinations are:
- LFO 1: amplitude
- LFO 2: filter.


LçFO



edit ENVELOPE
each layer features 3 EGs:
- EG1 amplitude: 4 stages ADSR
- EG2 filter: 4 stages ADSR
- EG3 pitch: 4 stages ADSR
Special legato articulation control from M-SE1 has not been implemented.


decaymodule




edit
EFFECTS section manages:
- 6 reverbs + 2 delays
- 3 choruses.
This section also cannot be edited or applied to a specific multitimbral part as it is only master.



edit MEMORY:
- 18 performances
- 226 patches
- 2 rhythm sets
- 1 global setup
There is no patch RAM slots for save andperformance can bulk dumps data to Midi for recall.

circuit bent





edit MODIFICATION some experimental bending on this machine but I did not have some great results! there's a short demo in the relative section below check it out.

circuit bending



edit RELATED FAMILY:

dance tr909

M-bd1 BASS DRUM - Drum kits

M-dc1 DANCE - loops and sample

M-se1 STRINGS - orchestral strings

M-vs1 VINTAGE - analog synth

M-gs64 CANVAS - Gs midi module




effet VST PLUGIN / SAMPLED VERSION there are some free and commercial samples set:

  name price link demo
free sample pack

FREE
MOC1- sampled strings kit for free!!

A MOC1 sample pack FROM US!!

effet n/a




demo AUDIO DEMO

demo factory demo 1
demo factory demo 2
demo factory demo 3
demo factory demo 4
demo circuit bent unit (experimental noises)




video YOUTUBE VIDEO CLIP SELECTION

moc1 video
demo



audio demo





manual
ROLAND M-OC1 MANUAL








manual
SERVICE MANUAL









Roland MOC1 RESET FACTORY


hold the F3 and power on.

edit






ROLAND M-OC1 FOR SALE
ROLAND M-OC1 FOR SALE
CHECK OUT EBAY OFFERS








circuit moc1 logo back panel


manual

-cheap
-still decent sounds


manual
-edit
-memory
-outdated PCM

comment


REVIEW "Edit is pain! orchestral VST are now far far better, but MOC1 offers some good sounds if you like ready-sounds-to go it is a nice orchestral support at now bargain price. "
